Semi-steel radial tire type A curing bladder

E-mail:

Mobile:

View similar products

Semi-steel radial tire curing bladder

Label List

Curing bladder

Product Description

Product Details

Capsule code	Clip edge Inner diameter	Clip edge Height	Clip edge Width	Neck Thickness	Middle Thickness	outer diameter	Total height	Section Perimeter	Exhaust line Model	Applicable tire specifications
Bladder Code	Foot I.D dB(mm)	Foot Height a(mm	Foot Width B (mm)	Foot Gauge To'(mm)	Centra Gauge To(mm)	Outside Diameter DB(mm)	Over-all Height HB(mm)	Effective Periphery LB(mm)	Etching Pattern	Applied Tyre Size
RA145	240	14.5	15	9	6	428	250	310	Plain twill 1#	145R12
RA1452	260	13.5	13	7	6		240	350	Gravel pattern 3#	165/175R13
RA1851	260	13.5	15	8	6	467	320	410	Gravel pattern 3#	185R14
RA1651	261	13.5	14.5	7	5	473	265	337.5	Plain twill 1#	165/70R13
RA1951	261	13.5	14.5	7	5	510	295	428	Gravel pattern 3#	195/185R14
RA2051	261	13.5	15	8	6	525	340	490	Gravel pattern 3#	ST205/215/75R15
RA13-06H	271	13.5	14.5	8	6	606	279	623.3	Plain twill 1#
RA12-14.5/373T	271	13.7	14.5	7.5	4	348	210	270	Gravel pattern 3#
RA 12 × 198 × 530	285	14.5	15	8.5	6	530	210	420	Gravel pattern 3#
RA 12 × 210 × 640	285	14.5	15	8.5	6	640	305	565	Gravel pattern 3#
RA 12 × 243 × 515	285	14.5	15	9	6	515	310	498	Gravel pattern 3#
RA 12 × 247 × 555	285	14.5	15	9	6	555	320	500	Gravel pattern 3#
RA 12 × 253 × 640	285	14.5	15	9	6	640	345	615	Gravel pattern 3#
RA215R17-1	285	14.5	15	9	5.75	483	365	466	Gravel grid 5#
RA215R18-1	285	14.5	15	9	5.75	483	379	489	Gravel grid 5#
RA2351B	310	13.5	15	8	6	620	445	608	Gravel pattern 3#	ST235/85R16
RA6501	310	13	16	8	6	580	350	510	Gravel pattern 3#	6.50/7.00/7.50R16
RA7001	310	13.5	16	8	6	620	330	527	Gravel pattern 3#	7.00R16
RA1852	314	13.5	16.5	6.5	5	495	320	431	Gravel pattern 3#	185/60R15
RA2251	314	13.5	16.5	6.5	5	510	360	477	Gravel pattern 3#	225/50R16
RA2252	314	13.5	16.5	6.5	5	535	350	485	Gravel pattern 3#	215/60R16 205/60R16
CS(RACS)15-6	314	13.5	16.5	7	5	584	315	484	Gravel pattern 3#	175R16C 195/70R15C 205/60R16215/60R16
CS(RACS)16-4	314	13.5	16.5	6.5	6	646	360	561.5	Gravel pattern 3#	LT235/85R16
BA2351B	334	13.5	16.5	6.5	5	590	384	558	Gravel pattern 3#	235/75R15C/23 5/75R16C/235/7 5R115
